Brakes Front: Disc brake, twin - Brakes Rear: Sealed oil-bathed multi-disc - Curb Weight: 300 kg (661 lbs) - Final Drive: Shaft drive - Fuel Tank Capacity: 17.5 L (4.6/3.8 US/Imp gal) - Ground Clearance: 280 mm (11.0 in) - Overall Length: 2115 mm (83.3 in) - Overall Width: 1210 mm (47.6 in) - Seat Height: 920 mm (36.2 in) - Suspension Front: Independent, double wishbone, coil spring, oil damped - Suspension Rear: Independent, double wishbone, coil spring, oil damped - Tires Front: AT25 x 8-12, tubeless - Tires Rear: AT25 x 10-12, tubeless - Transmission: Automatic variable ratio (V-belt), with high-/low-range, and reverse - Wheelbase: 1285 mm (50.6in) - Bore Stroke: 87.5 mm x 82.0 mm (3.228 in) - Compression Ratio: 10.0 : 1 - Engine: 493cc (30 cu. in.), 4-stroke, liquid-cooled, SOHC - Fuel System: Fuel injection - Ignition: Electronic ignition (CDI) - Lubrication: Wet Sump - Starter: Electric - Warranty: 12 month limited warranty.
